СКУ: LE1M35P7
Устройства за директен пуск 1,1KW 3P 230
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Rated operation power at AC-3, 400 V
11
-
Voltage type for actuating
EV000460
-
Degree of protection (IP)
EV006421
-
Rail mounting possible
FALSE
-
Type of electrical connection for auxiliary- and control current circuit
EV000415
-
Degree of protection (NEMA)
EV000154
-
Rated control supply voltage Us at AC 50HZ
415
-
Rated control supply voltage Us at AC 60HZ
415
-
Number of normally closed contacts as main contact
-
Number of normally open contacts as main contact
3
-
Rated operation current Ie at AC-3, 400 V
12
-
Function
EV003959
Easy TeSys Control contactor 3 poles for motor applications up to 95A 45kW/440V. It provides a 380V 50Hz AC coil, 1NO+1NC built-in auxiliary contacts, power and control connections by screw clamp terminals. 85mm width for standard. It provides standard reliability and durability with 0.9 Mcycles electrical durability AC-3 and 3 Mcycles mechanical durability. Operating rates up to 1200 cycles per hour. It can cover -5°C to 55°C working temperature and mounted by DIN-rail. No derating up to 3000m altitude. Available worldwide, it is multi-standards certified (CB scheme,CE,CCC,EAC) and Environmental compliant (RoHS/REACH).
