СКУ: A9MEM3250

Трифазен електромер kWh ток. трансф. MODBUS

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Width
    90
  • Width in number of modular spacings
    5
  • Frequency
    50
  • Degree of protection (NEMA)
    EV000599
  • Depth
    69
  • Pulse output
    EV003671
  • Pulse type
    EV010953
  • Escapement mechanism
    FALSE
  • Accuracy class
    EV000074
  • Type of indication
    EV005572
  • Mounting method
    EV006471
  • With lock code
    FALSE
  • Suitable for
    EV010966
  • Type of meter
    EV000101
  • Nominal voltage (Un) N-L
    100
  • Model
    EV010942
  • Energy type
    EV010946
  • Measurement type load profile
    FALSE
  • EEC40 signature
    FALSE
  • Height
    95
  • Nominal current (In)
    63
  • Calibrated
    FALSE
  • Approval
    EV010950
  • Tariff control
    EV010949
  • Pulse rate
  • Number of positions total (counter)
    9
  • Tariff type
    EV010947
  • Pole type
    EV011974
  • Nominal voltage (Un) L-L
    173
  • Max. current (Imax)
    63
  • Type of interface
    EV007520

The Acti9 iEM3000 series energy meters offer an attractive range of three-phase DIN rail-mounted energy meters with an LCD display. Additional local signaling includes green LED power-on indicator, flashing yellow LED for accuracy checking and communication indicators. This meter can be used in sub-billing applications and supports 4 tariff schedules. The meter provides the following accuracy classes: Active Energy: class 1 per IEC 62053-21, Active Energy: class B per EN 50470-3 and Active Energy: class 1 per IEC 61557-12. The meter will measure Active and Reactive Power, Active and Reactive Energy. Designed for 50Hz or 60Hz networks, supply voltage can range from 100 to 277VAC or 173 to 480VAC. Line rated current for this meter is up to 63A direct connect and will support Single Phase and Neutral, Three Phase and Three Phase and Neutral configurations. No primary communication ports. There are two digital inputs for Tariff control. Certifications include EAC, CE, UL and MID. Product dimensions are as follows: width 3.54 in (90 mm), depth 2.72in (69 mm), height 3.74 in (95 mm) and product weight 9.17 oz (260 g).
