СКУ: 31180
Товаров прекъсвач INV100 3P 100 A R/Y - VISIBLE BREAK SWIT
-
Brand
Schneider Electric
-
Material housing
EV000139
-
Width
270
-
With transparent cover
TRUE
-
Degree of protection (IP)
EV006420
-
Model
EV000945
-
Depth
235
-
Height
360
-
Suitable for emergency stop
TRUE
This Compact INV100 is a 3P non-automatic switch-disconnector with visible break, red rotary handle and yellow front. It is suitable for isolation with positive contact indication, as defined by IEC 60947-1 and IEC60947-3 standards. The operational current is 100A at 415VAC in categories AC21A, AC22A and AC23A. The rated voltage is 690VAC 50/60Hz or 250VDC. Compact INV range allows the visible break of the main contacts through a transparent cover. It can be used as an emergency-off device. For easy identification, it uses special colours stipulated by the standards. The red rotary handle is designed to offer easy operation and high performance in interruption of currents. Compact INV100 is a class II insulation level front-face device as per IEC 60664 standard.
