СКУ: 31134
Товаров прекъсвач Compact INS630 - 630 A - 3 полюса
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Suitable for intermediate mounting
FALSE
-
Suitable for floor mounting
FALSE
-
Suitable for distribution board installation
TRUE
-
Type of control element
EV004095
-
Material housing
EV000139
-
Number of poles
4
-
Degree of protection (IP), front side
EV006415
-
With zero (off) position
TRUE
-
With retraction in 0-position
FALSE
-
Model
EV009208
-
Complete device in housing
TRUE
-
Suitable for front mounting
FALSE
-
Rated permanent current Iu
400
This Compact INS630 is a 3 poles non-automatic switch-disconnector with red rotary handle and yellow front. It is suitable for isolation with positive contact indication, as defined by IEC 60947-1 and IEC60947-3 standards. The operational current is 630A at 415VAC in categories AC22A and AC23A. The rated voltage is 690VAC 50/60Hz or 125VDC with 2 Poles in series. It can be used as an emergency-off device. For easy identification, it uses special colours stipulated by the standards. The red rotary handle is designed to offer easy operation and high performance in interruption of currents. Compact INS630 is a class II insulation level front-face device as per IEC 60664 standard.
