СКУ: VW3G4702
Terminal protective covers IP20
-
Brand
Schneider Electric
-
Suitable for EX-applications
FALSE
-
Number of cells
1
-
Weight
6
-
Other indications
EV000494
-
Model
EV003088
-
Size indication
EV007978
-
Diameter
25
-
Nominal voltage
3
-
Height including pole
5
The protective covers for power terminals are part of the Altivar Soft Starter master range. They provide an IP20 protection rating for soft starters where the mains and motors connect to unprotected bars. This accessory is designed for the Altivar Soft Starter ranges ATS490 and ATS430, with an operational rated current between 140A and 170A. It provides an IP20 protection degree for both power connections and the overall product. The protective cover for the power terminal consists of two plastic parts. The two parts of the protective cover are securely fitted together around the entire connection. When assembled, the two parts of the accessory have dimensions of 56mm (width) x 47mm (length) x 75mm (height) and a weight of 0.036kg. It conforms to REACH regulation and RoHS directive. The kit contains six protective covers along with an instruction sheet. The installation of the protective covers does not require any tool. The built-in and innovative features of the ATS490 range improve competitiveness, operational resilience, and equipment sustainability. ATS490 delivers excellence in mastering applications and costs, even for the most demanding requirements.
