СКУ: 13982
ТАБЛО KAEDRA 18 MOD (A)
-
Brand
Schneider Electric
-
Rated permanent current Iu
125
-
Number of poles
2
-
Colour
EV000202
-
Length
432
-
Insulated
TRUE
-
Cross section
16
-
Number of phases
1
-
Type of electric connection
EV000158
-
Width in number of modular spacings
24
-
Suitable for devices with auxiliary switch
FALSE
-
Suitable for devices with N-conductor
TRUE
-
Module width
27
-
Max. rated operation voltage Ue
500
-
Suitable for number of devices
8
This Mureva Enclosure weatherproof versatile enclosure up to 12 modules in 2 rows comes with reversible transparent cover. The total number of modules is 24. The dimensions of the box are (W) 340mm x (H) 460mm x (D) 160mm. The rated current is 63A and the complete insulation is Class 2. The degree of protection is IP65 and IK09. The color of the enclosure is light grey (RAL 7035). The operating temperature are between -25°C to 60°C. Empty, this enclosure is compliant with IEC 60670. Equipped switchboards, this enclosure is compliant with IEC 60493-3. This enclosure is dedicated to indoor or outdoor waterproof installation.
