SCHNEIDER ELECTRIC Switch disconnector EasyPact CVS160NA, 3P, 160A, AC22A, AC23A | Spark & Co
  • 3D
|

СКУ: LV516425

SCHNEIDER ELECTRIC Switch disconnector EasyPact CVS160NA, 3P, 160A, AC22A, AC23A

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Version as emergency stop installation
    FALSE
  • Version as reversing switch
    FALSE
  • Suitable for front mounting centre
    TRUE
  • Number of poles
    3
  • Voltage release optional
    FALSE
  • Device construction
    EV009211
  • Version as maintenance-/service switch
    FALSE
  • Version as safety switch
    FALSE
  • Suitable for front mounting 4-hole
    TRUE
  • Number of switches
    1
  • Motor drive integrated
    FALSE
  • Suitable for floor mounting
    FALSE
  • Motor drive optional
    FALSE
  • Version as main switch
    TRUE
  • Interlockable
    TRUE
  • Colour control element
    EV000206
  • Suitable for distribution board installation
    TRUE
  • Degree of protection (IP), front side
    EV006415
  • Rated permanent current Iu
    160
  • Rated permanent current at AC-23, 400 V
    160
  • Number of auxiliary contacts as change-over contact
    4
  • Type of control element
    EV000421
  • Rated operating voltage
    220
  • Suitable for intermediate mounting
    TRUE
  • Max. rated operation voltage Ue AC
    440
  • Rated short-time withstand current lcw
    2.5
  • Number of auxiliary contacts as normally closed contact
  • Number of auxiliary contacts as normally open contact

This device is a 160A switch disconnector from EasyPact CVS160. This operational current(Ie) is both 160A, when is used for utilisation category AC22 or AC23. The rated short-time withstand current(Icw) is 2500A(1s). The version of device is 3poles frame without tripping protection. It is conformed to standard EN/IEC60947-3 for switch disconnector products. This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95. It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation. The front of toggle offers IP40 protection, but when it is equipped extended rotary handle, additional IP54 protection degree for extended rotary handle. This series have slots for control auxiliaries(MN/MX), which is indicated contact status. The fixed dimension is 140mm width, 255mm height, 110mm Depth.
