СКУ: LUCAX6BL
SCHNEIDER ELECTRIC Standard control unit 0.15-0.6A, 3P motors, thermal magnetic protection, 24VDC
-
Brand
Schneider Electric
-
Number of poles
3
-
Rated permanent current Iu
32
-
Voltage type for actuating
EV000509
-
With ground fault protection function
TRUE
-
Short-circuit release function
EV003978
-
Rated control supply voltage Us at AC 50HZ
110
-
Rated control supply voltage Us at AC 60HZ
110
-
Rated control supply voltage Us at DC
110
-
Type of motor protection
EV001281
-
Initial value of the undelayed short-circuit release - setting range
416
-
End value adjustment range undelayed short-circuit release
416
-
Overload release current setting
8
TeSys U control and diagnostic unit to be inserted in advanced power bases LUB120, LUB320, LUB380 to form a TeSys U starter controller, for 3-phase motor applications up to 1.5kW at 400V. It provides full protection to motors with a rated current Ir 1.25-5A (Ir adjustable), overload tripping class 10, short circuit at 13 x Irmax, overcurrent at 14.2 x Ir, phase loss, insulation fault (protection of equipment only). It provides a thermal overload alarm to be used locally using a LUFDA module or remotely using a LULC module, and a test push button for overload simulation. To be used with a 24V DC voltage for the control of the starter (through the control terminals A1/A2 located in the power base). Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine).
