SCHNEIDER ELECTRIC Shunt trip SHT, EasyPact EZC100, EasyPact CVS100BS, 380VAC to 480VAC, 50/60 Hz | Spark & Co
  • 3D
|

СКУ: EZASHT380AC

SCHNEIDER ELECTRIC Shunt trip SHT, EasyPact EZC100, EasyPact CVS100BS, 380VAC to 480VAC, 50/60 Hz

  • Brand
    Schneider Electric
  • Type of electric connection
    EV000415
  • Voltage type for actuating
    EV000460
  • Suitable for power circuit breaker
    TRUE
  • Suitable for motor safety switch
    FALSE
  • Suitable for off-load switch
    FALSE
  • Suitable for overload relay
    FALSE
  • Rated control supply voltage Us at AC 50HZ
    380
  • Rated control supply voltage Us at AC 60HZ
    380
  • Number of contacts as change-over contact

The under voltage release(UVR) as the part of remote tripping is used for EasyPact EZC100 circuit breakers. This UVR is worked at 200~277VAC voltage(Un),50/60Hz. Tripping threshold is between 0.35 and 0.7times the related voltage. This release trips the circuit breaker when control voltage rises drops below a tripping threshold. Circuit breaker closing is possible only if the voltage exceeds 0.85 times the related voltage. This installation of SHT is external mounting.
