SCHNEIDER ELECTRIC Safety Relay 24V AC/DC

This product belongs to the Harmony XPSU range of safety relays. It monitors E-stop, guard/magnetic/RFID switches, PNP sensors, light curtains & two-hand controls. The safety relay is powered with 48-240V AC/DC, and equipped with a screw removable terminal block. This universal safety module embeds pre-defined safety functions, or selectable safety functions via rotary selectors. It features 1 safety input, 2 configurable ON/OFF pulsed outputs, 1 changeover safety output, and 1 solid-state diagnostic output. The maximum safety level achieved by this safety relay is PLc conforming to ISO 13849-1, SILCL 1 conforming to IEC 62061 and SIL 1 conforming to IEC 61508. It weighs 0,200kg and measures 22,5mm (Width) x 120mm (Depth) x 100mm (Height). This safety relays is suitable for applications such as Food and Beverage, Hoisting, Material Handling, Material Working, Packaging. It conforms to IEC60947-5-1, IEC61508-1/2/3, ISO13849-1, IEC62061 functional safety standards, is certified by cULus, TÜV, EAC, CCC and KC marking. Harmony safety relays are compatible with Modicon logic controllers. This relay is mounted on a 35mm symmetrical DIN rail. Harmony XPS Basic and Universal relays simplify single safety function management for machines of low to medium complexity. Harmony XPS Universal is the first choice for a broad range of simple to mid-complex machines.
