СКУ: METSEPM2120
SCHNEIDER ELECTRIC Power & Energy meter EasyLogic PM2120, HS code: 90283090, COO: IN, 0.3kg
-
Brand
Schneider Electric
-
Mounting method
EV000242
-
Width
90
-
Voltage type
EV000509
-
Supporting protocol for LON
FALSE
-
Supporting protocol for Modbus
TRUE
-
Model
EV010943
-
Measured value memory
FALSE
-
Indication
EV005572
-
Measurement type load profile
FALSE
-
Height
95
-
Max. current (Imax)
6
-
Pole type
EV011974
-
Nominal current (In)
5
-
Frequency measurement
TRUE
-
Effective power
TRUE
-
Power factor
TRUE
-
Min. value storage
TRUE
-
Wth communication interface M-Bus
FALSE
-
Apparent power
TRUE
-
Top arbour measurement
TRUE
-
With communication interface according to EN 62056-21
FALSE
-
Reactive power
TRUE
-
With communication interface RS-485
TRUE
-
Accuracy class
0.5
-
Step angle (cos phi)
FALSE
-
Max. value storage
TRUE
-
With communication interface KNX
FALSE
-
Measuring range
80
This product is part of the Lexium 32 range, an offer of motion servo drives for machines from 0.15kW to 7kW. The AC motion servo drive for one axis, features with an integrated EMC filter, compact drive with analogue inputs and pulse train. It provides 2 safety, 6 logic discrete inputs and 5 discrete outputs. Thanks to its compact design this servo drive enables to save on cabinet space and size, reduces the machine footprint and decreases costs. It is a motion servo drive with a rated supply voltage of 100V to 120V, 200V to 240V (single phase), a continuous output current of 3A at 8kHz and a continuous power of 900W at 230V. It is furnished with terminal for electrical connection and RJ45 connector for Modbus integrated communication interface. It is an IP20 rated product. Its dimensions are 48mm (Width) x 237mm (Depth) x 270mm (Height). It weighs 1.7kg. This product is certified by CE, CSA, RoHS, TUV and UL. It meets EN/IEC 61800-3 and EN/IEC 61800-5-1 standards. This product is compatible with servo motors BMH and BSH. Servo drive range with four servo drive models and two servo motor families plus an intelligent selection of options. It provides you with the drive and motor combination that has exactly the right power, performance and functionality.
