SCHNEIDER ELECTRIC Discrete output module, Modicon TM3, 16 relay outputs (spring) 24 VDC

This digital output module is part of the Modicon TM3 range of I/O expansion modules for Modicon controllers. It consists in 16 N/O relay outputs 2 A. It is equipped with one removable screw terminal block and can be mounted on a symmetrical DIN rail 35 mm. This digital I/O module complement the embedded I/O on Modicon M221, M221 Book, M241 and M251 logic controllers. There is an insulation between the output and the internal logic at 2300V AC, outputs at 750V AC, and output groups at 1500V AC. Fitted with removable spring terminals for input and output connections, 5.08 mm pitch, IP20 rated. It measures 23.6mm wide x 70mm deep, 90mm high, and weighs 0.14kg. It is CE certified and compliant with EN/IEC 61131-2 and EN/IEC 61010-2-201 standards. It is compatible with Modicon M262, Modicon M241, Modicon M251, and Modicon M221 logic controllers. It is delivered in 1 package (PCE type). It supports TH35-15 and TH35-7.5 top-hat rails (IEC 60715) and plate/panel installation with fixing kit. Modicon TM3 I/O system enables flexible, customizable expansion of controller I/O terminals. Boost the performance of your controller with the Modicon TM3 I/O system specially designed for the Modicon M221, M241 and M251 logic controllers.
