СКУ: A9XPC712
SCHNEIDER ELECTRIC Comb busbar iC40 3PN 12 modlules 18mm
-
Brand
Schneider Electric
-
Rated permanent current Iu
80
-
Number of poles
2
-
Colour
EV000202
-
Insulated
TRUE
-
Number of phases
1
-
Type of electric connection
EV000158
-
Suitable for devices with auxiliary switch
FALSE
-
Suitable for devices with N-conductor
TRUE
-
Length
862
-
Width in number of modular spacings
48
-
Module width
9
-
Max. rated operation voltage Ue
230
-
Suitable for number of devices
48
This Acti9 product is a cuttable horizontal comb busbar for Acti9 iC40. It is dedicated to (Neutral, Line) installations. The distribution type is (N, L1), (N, L2), (N, L3). It is a set of 1 product. It is suitable for 16 devices with 3P+N pole and without associated auxiliaries. The length is 862mm. The total number of modules of 18mm is 48. The Ie rated operational current at 40°C is 80A. The Ui rated insulation voltage is 400VAC. The Ue rated operational voltage is 230VAC (phase/neutral) and 400V (phase/phase). The color of the device is white (RAL 9003). The pollution degree is 3. The degree of protection is IP20 with end-pieces and tooth covers. According to IEC 60695-2-1 standard, the fire resistance is self-extinguishing at 960°C within 30s. It complies with EN/IEC 61439-1 standard.
