SCHNEIDER ELECTRIC Circuit breaker, ComPacT NSX100F AC/DC, 18kA/415VAC, 2P, TMD trip unit 100A | Spark & Co
  • 3D
|

СКУ: C10F2TM100

SCHNEIDER ELECTRIC Circuit breaker, ComPacT NSX100F AC/DC, 18kA/415VAC, 2P, TMD trip unit 100A

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Number of poles
    3
  • Device construction
    EV009211
  • Rated operating voltage
    690
  • Degree of protection (IP)
    EV006415
  • With integrated under voltage release
    FALSE
  • Width
    105
  • Type of control element
    EV000154
  • With integrated auxiliary switch
    FALSE
  • Switch off technique
    EV006116
  • With thermal protection
    FALSE
  • Rated permanent current Iu
    6.3
  • Height
    161
  • Phase failure sensitive
    FALSE
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    36
  • Depth
    86
  • Adjustment range undelayed short-circuit release
    37.8

ComPacT NSX 100F is a complete 2 poles fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 18kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 25A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an fixed thermal overload protection and a fixed magnetic protection. The dimension is 161mm x 70mm x 86mm (H x W x D). It is compliant with international standards (EN/IEC 60947), CCC, EAC and marine specifications.
