СКУ: A9XPH312
SCHNEIDER ELECTRIC Busbar - 3L, 12 modules, 100A
-
Brand
Schneider Electric
-
Number of poles
1
-
Colour
EV000202
-
Width in number of modular spacings
6
-
Insulated
TRUE
-
Cross section
16
-
Number of phases
1
-
Type of electric connection
EV000158
-
Suitable for devices with N-conductor
FALSE
-
Rated permanent current Iu
100
-
Suitable for devices with auxiliary switch
TRUE
-
Module width
18
-
Max. rated operation voltage Ue
415
-
Length
110
-
Suitable for number of devices
6
This Acti9 Vigi iC40 is a modular add-on residual current devices. It is a 3P+N and rated current is 40A. The earth leakage protection class is AC type with a sensitivity of 300mA and a voltage independent technology. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. A VisiTrip window is here to indicate a fault tripping by a red mechanical indicator on the front face. This product is compliant with EN/IEC 61009-2-1 standard. Electrical endurance goes up to 10000 cycles. Mechanical endurance goes up to 20000 cycles. The Ue rated operational voltage is 400VAC. The Ui rated insulation voltage is 440VAC. The Uimp rated impulse withstand voltage is 4kV. The pollution degree is 3. It can be mounted on DIN rail. The width in 9mm pitches is 4. The product color is white (RAL9003). The dimensions are (W) 90mm x (H) 99.5mm x (D) 74mm. The degree of protection is IP20 and IP40 in an enclosure. The operating temperature is -5°C to 60°C. The storage temperature is -40°C to 85°C.
