СКУ: RM17UAS15

SCHNEIDER ELECTRIC 1-phase voltage control relay, 5A, 1CO, 65..260V AC/DC

  • Brand
    Schneider Electric
  • Type of electric connection
    EV000415
  • Depth
    72
  • Number of contacts as change-over contact
    1
  • With detachable clamps
    FALSE
  • Voltage type for actuating
    EV000509
  • Height
    90
  • Rated control supply voltage Us at AC 50HZ
    110
  • Rated control supply voltage Us at AC 60HZ
    110
  • Rated control supply voltage Us at DC
    110
  • Number of contacts as normally closed contact
  • Number of contacts as normally open contact
  • Width
    17.5
  • Max. permitted off-delay time
    10
  • Min. adjustable off-delay time
    0.1
  • Single-phase over voltage possible
    TRUE
  • Single-phase under voltage possible
    TRUE
  • Contains function DC-over voltage
    FALSE
  • Max. permitted delay-on energization time
    0.5
  • Contains function DC-voltage hysteresis
    FALSE
  • Type of voltage measuring range
    EV000509
  • Three-phase over voltage possible
    FALSE
  • Three-phase under voltage possible
    FALSE
  • Contains function DC-under voltage
    TRUE
  • Three-phase hysteresis possible
    FALSE
  • Voltage measuring range 1
    65
  • Response value voltage
    50
  • Single-phase hysteresis possible
    FALSE

This Harmony RM17-U control relay allows monitoring of voltage control. This modular control relay is ideal for monitoring of electrical values and voltage variation in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market slimmest form-factors with 17.5mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. It also offers a selectable memory function, integral LED for indicating control status, sealable cover, with simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. Multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC.
