СКУ: LC2K12107B7
Реверсивен контактор 3P+F FAST 24V50/60H
-
Brand
Schneider Electric
-
Rated operation power at AC-3, 400 V
5.5
-
Degree of protection (IP)
EV006405
-
Voltage type for actuating
EV000460
-
Rated control supply voltage Us at AC 50HZ
24
-
Rated control supply voltage Us at AC 60HZ
24
-
Rail mounting possible
FALSE
-
Type of electrical connection for auxiliary- and control current circuit
EV000415
-
Degree of protection (NEMA)
EV000154
-
Function
EV003958
-
Number of normally open contacts as main contact
3
-
Rated operation current Ie at AC-3, 400 V
12
-
Rated operation power NEMA
5.59
-
Type of electrical connection of main circuit
EV003968
-
Number of normally closed contacts as main contact
TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (4kW/440V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V 50/60Hz AC coil,1NO built-in auxiliary contact, connection by faston connectors. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. With feature (90mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).
