СКУ: LC2K09015E7
reversing Контактор, TeSys K, 3P, AC-3/AC-3e,440V 9A, 1NC, 48V AC coil, solder pins for printed circuit boards
-
Brand
Schneider Electric
-
Rated operation power at AC-3, 400 V
4
-
Degree of protection (IP)
EV006405
-
Voltage type for actuating
EV000460
-
Rated control supply voltage Us at AC 50HZ
48
-
Rated control supply voltage Us at AC 60HZ
48
-
Rail mounting possible
FALSE
-
Degree of protection (NEMA)
EV000154
-
Function
EV003958
-
Number of normally open contacts as main contact
3
-
Rated operation power NEMA
3.73
-
Rated operation current Ie at AC-3, 400 V
9
-
Type of electrical connection of main circuit
EV003963
-
Type of electrical connection for auxiliary- and control current circuit
EV000154
-
Number of normally closed contacts as main contact
TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V). It provides 48V 50/60Hz AC coils, 2NC built-in auxiliary contacts, connection by solder pins for printed circuit board. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With mechanical interlock (without electrical interlocking), this model has no pre-wired reversing power connections. Multi standards certified (IEC, UL, CSA, CCC, EAC).
