СКУ: RM22UB34
Реле VOLTAGE CONTROL RELAY RM22-UB - RANGE 80
-
Brand
Schneider Electric
-
Type of electric connection
EV000415
-
With detachable clamps
FALSE
-
Rated control supply voltage Us at AC 50HZ
24
-
Rated control supply voltage Us at AC 60HZ
24
-
Voltage type for actuating
EV000509
-
Rated control supply voltage Us at DC
24
-
Height
90
-
Number of contacts as change-over contact
2
-
Depth
73
-
Min. adjustable off-delay time
0.1
-
Width
22.5
-
Max. permitted off-delay time
30
-
Min. adjustable delay-on energization time
0.1
-
Single-phase over voltage possible
TRUE
-
Single-phase under voltage possible
TRUE
-
Single-phase hysteresis possible
TRUE
-
Type of voltage measuring range
EV000509
-
Three-phase over voltage possible
FALSE
-
Three-phase under voltage possible
FALSE
-
Contains function DC-under voltage
TRUE
-
Contains function DC-over voltage
TRUE
-
Three-phase hysteresis possible
FALSE
-
Contains function DC-voltage hysteresis
TRUE
-
Number of contacts as normally closed contact
-
Number of contacts as normally open contact
-
Max. permitted delay-on energization time
30
-
Voltage measuring range 1
80
-
Response value voltage
60
This Harmony RM22-UB relay allows monitoring of voltage control in single phase networks. This modular multi function single phase voltage control relay is ideal for monitoring of electrical values in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market slim form-factors with 22.5mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. It also offers a diagnostic button, sealable cover, simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC.
