Рамка/Корпус, SM AirSeT, таван, без горна кабелна връзка, IAC AFL 16-20kA или IAC AFLR 12,5-16-20kA, W375mm | Spark & Co
  • 3D
  • 3D
|

СКУ: SR7ROOFS375ADV

Рамка/Корпус, SM AirSeT, таван, без горна кабелна връзка, IAC AFL 16-20kA или IAC AFLR 12,5-16-20kA, W375mm

  • Brand
    APC Brand
  • Voltage type
    EV000460
  • SNMP
    FALSE
  • Potential free switch contact
    FALSE
  • Input voltage
    230
  • Number of output connections C13
    6
  • Number of output connections with protective contact (SCHUKO)
  • Suitable for network-management
    FALSE
  • Number of output connections fixed connection
  • With communication interface RS-232
    FALSE
  • Number of phases primary
    1
  • Auto shut down function
    FALSE
  • Secondary frequency
    50
  • Number of phases secondary
    1
  • Construction type
    EV000870
  • Output voltage
    230
  • Modular
    FALSE
  • Number of output connections French standard (Type E)
  • USB interface
    TRUE
  • Efficiency in eco-mode
    94
  • Overall efficiency
    88
  • Primary frequency
    40
  • USV- technology
    EV007607
  • Input connection
    EV010685
  • Output apparent power
    3000
  • Width
    85
  • Output power factor
    0.9
  • Output effective power
    2700
  • Height
    432
  • Number of output connections C19
    2
  • Max. voltage distortion output (linear load)
    0.02
  • Bridging time full load
    3.58
  • Weight
    31.3
  • Depth
    635

This RM AirSeT is a medium voltage gas insulated switchgear (GIS). It comprises 2 functional units: 1 switch-disconnector I, 1 circuit breaker B. It applies for a rated voltage up to 24kV. The rated busbar current is 630A. The short circuit current is up to 20kA for 1s or 3s. It conforms the standards IEC 62271-200 and IEC 62271-1 for indoor installation. The familiar 3 positions switch-disconnectors use Shunt Vacuum Interruption (SVI)™ technology including load breaking, disconnecting and earthing. The circuit breakers on the top of B functional units are interlocked with 3 position disconnectors directly connected to cable bushings. Breaking / switching is insured in vacuum interrupters. The gas of disconnection and insulation is pure air. The pure air, main contacts, vacuum interrupters and busbar are preserved from ambient environment in a IP67 stainless steel sealed pressure system, for the service life. Its footprint is similar to previous generations, for applications as ring main unit (RMU) or modular unit. Opening the link on the nameplate’s QR code at site, provides a digital access to products data. Monitoring and control functionalities can be implemented with the advanced PowerLogic devices (fault passage indication, remote telecontrol units, power quality…). Some kits (motorisation…) and tutorials including videos are available for further upgrade. The dimensions are width (W): 770mm x depth (D) 780mm x height (H) 1625mm in standard 1.6 (or 1400mm in version 1.4) without extended Low Voltage cabinet. The standard operating temperature is -25°C to 40°C. The storage temperature is -40°C to 70°C.
