СКУ: 21103
Прекъсвач - P25M - 3P - 0.63A - K крива
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Concurrently switching neutral conductor
FALSE
-
Frequency
50
-
Rated insulation voltage Ui
690
-
Additional equipment possible
TRUE
-
Rated voltage
400
-
Flush-mounted installation
FALSE
-
Explosion-proof
FALSE
-
Connectable conductor cross section multi-wired
1
-
Pollution degree
3
-
Number of poles (total)
3
-
Number of protected poles
3
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
100
-
Built-in depth
44
-
Width in number of modular spacings
2.5
-
Rated impulse withstand voltage Uimp
6
-
Release characteristic
EV000247
-
Voltage type
EV000460
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
100
-
Connectable conductor cross section solid-core
1
-
Over voltage category
3
-
Ambient temperature during operating
-20
-
Rated current
2.5
This Acti9 P25M is a low voltage motor circuit breaker. It is a 3P circuit breaker with 3 protected poles, 2.5A rated current and K tripping curve. The Icu rated short circuit breaking capacity is up to 3kA at 690VAC conforming to EN/IEC 60898-1 standard. This product complies with both residential standard EN/IEC 60898-1 and industrial standard EN/IEC 60947-2. This miniature circuit breaker combines functions of circuit protection against short circuit and overload current, control and isolation. The motor protection cicuit breaker Acti9 P25M is designed for installation in modular final distribution enclosures. The Ue operational voltage is 440VAC. The Ui rated insulation voltage is 690VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 5 pitches of 9mm. The dimensions are (W) 45mm x (H) 89mm x (D) 70mm. The weight is 0.26kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -20°C to 60°C. The storage temperature is -40°C to 80°C.
