СКУ: LV525509
Прекъсвач EasyPact CVS250F, 36 kA, 415 VAC, ETS 2.2, 250A, 4P
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Version as emergency stop installation
FALSE
-
Version as reversing switch
FALSE
-
Suitable for front mounting centre
TRUE
-
Number of poles
3
-
Voltage release optional
FALSE
-
Device construction
EV009211
-
Version as maintenance-/service switch
FALSE
-
Version as safety switch
FALSE
-
Suitable for front mounting 4-hole
TRUE
-
Number of switches
1
-
Motor drive integrated
FALSE
-
Suitable for floor mounting
FALSE
-
Motor drive optional
FALSE
-
Version as main switch
TRUE
-
Interlockable
TRUE
-
Colour control element
EV000206
-
Suitable for distribution board installation
TRUE
-
Degree of protection (IP), front side
EV006415
-
Rated permanent current Iu
250
-
Number of auxiliary contacts as change-over contact
4
-
Type of control element
EV000421
-
Rated permanent current at AC-23, 400 V
250
-
Rated operating voltage
220
-
Number of auxiliary contacts as normally closed contact
-
Number of auxiliary contacts as normally open contact
-
Suitable for intermediate mounting
TRUE
-
Max. rated operation voltage Ue AC
440
-
Rated short-time withstand current lcw
3.5
This device is a 3 poles 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized buildings protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a ETS 2.2 electric trip unit. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS250B is compliant with international standards (IEC 60947, EN 60947, CCC, CB).
