СКУ: LV516311

прекъсвач EasyPact CVS160B, 25kA, 415VAC, 100A термомагнитно изключващо у-во, 4P 3d

  • Brand
    Schneider Electric
  • Number of poles
    3
  • Motor drive integrated
    FALSE
  • Motor drive optional
    FALSE
  • Rated permanent current Iu
    40
  • Degree of protection (IP)
    EV006415
  • Number of auxiliary contacts as change-over contact
    2
  • Type of electrical connection of main circuit
    EV008864
  • Type of control element
    EV000421
  • Position of connection for main current circuit
    EV007926
  • Integrated earth fault protection
    FALSE
  • Suitable for DIN rail (top hat rail) mounting
    FALSE
  • With switched-off indicator
    TRUE
  • DIN rail (top hat rail) mounting optional
    TRUE
  • Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
    25
  • Device construction
    EV009311
  • Number of auxiliary contacts as normally closed contact
    2
  • Complete device with protection unit
    TRUE
  • Rated voltage
    440
  • Number of auxiliary contacts as normally open contact
    2
  • Overload release current setting
    32

This EasyPact CVS400NA is a complete 4 poles switch disconnector. It is used to control and isolate electrical distribution circuits and it requires an upstream protection. The operational current is 400A at 415VAC 50/60Hz for AC22A and AC23A utilisation categories. The operational voltage is 440VAC 50/60Hz. It comes with a variety of optional functions and accessories common with EasyPact CVS circuit breakers. The dimensions for this 4 poles version are 185mm x 255mm x 110mm. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.
