СКУ: LV510930
прекъсвач EasyPact CVS100BS, 25 kA, 415 VAC, 16 A номинален, термомагнитно изключващо у-во, 3P 3d
-
Brand
Schneider Electric
-
Number of poles
3
-
Motor drive integrated
FALSE
-
Motor drive optional
FALSE
-
Degree of protection (IP)
EV006415
-
Number of auxiliary contacts as change-over contact
2
-
Type of electrical connection of main circuit
EV008864
-
Type of control element
EV000421
-
Position of connection for main current circuit
EV007926
-
Integrated earth fault protection
FALSE
-
Suitable for DIN rail (top hat rail) mounting
FALSE
-
With switched-off indicator
TRUE
-
DIN rail (top hat rail) mounting optional
TRUE
-
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
25
-
Device construction
EV009311
-
Number of auxiliary contacts as normally closed contact
2
-
Complete device with protection unit
TRUE
-
Rated voltage
440
-
Number of auxiliary contacts as normally open contact
2
-
Rated permanent current Iu
16
-
Overload release current setting
12.8
EasyPact CVS100BS is a 3 poles 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized buildings protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. EasyPact CVS100BS current-limiting technology greatly reduces damage to installation caused by short-circuit current. This product embeds a 16A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. EasyPact CVS100BS is compliant with international standards (IEC 60947, CCC, EAC).
