СКУ: A9GSB692
Основа за предпазител, Acti9 SBI, 1P+N, 125A, за 22 x 58mm
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Concurrently switching neutral conductor
FALSE
-
Width in number of modular spacings
4
-
Frequency
50
-
Additional equipment possible
TRUE
-
Rated voltage
400
-
Voltage type
EV000509
-
Flush-mounted installation
FALSE
-
Explosion-proof
FALSE
-
Over voltage category
4
-
Connectable conductor cross section multi-wired
1
-
Pollution degree
3
-
Rated current
63
-
Number of poles (total)
4
-
Number of protected poles
4
-
Rated impulse withstand voltage Uimp
6
-
Release characteristic
EV000247
-
Connectable conductor cross section solid-core
1
-
Rated insulation voltage Ui
500
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
15
-
Current limiting class
3
-
Built-in depth
44.5
-
Ambient temperature during operating
-35
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
30
-
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
15
-
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
15
This Acti9 K60N product is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole and 50A In rated current and C tripping curve. The Icn rated short circuit breaking capacity goes up to 6000A at 230VAC conforming to EN/IEC 60898-1 standard. It complies with residential standard EN/IEC 60898-1. This miniature circuit breaker protects circuit against short circuit and overload current. The connection can be made downstream by biconnect comb busbar. It can be also made upstream/downstream by tunnel terminals. A padlock device is available for work to be carried out on live parts. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 440VAC. The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The product colour is white (RAL9003). The dimensions are (W) 18mm x (H) 81mm x (D) 70mm. The weight is 0.12kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -25°C to 70°C. The storage temperature is -25°C to 85°C.
