СКУ: A9N18568
Модул Vigi C120 - 3P - 500 mA - клас AC
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Number of poles
4
-
Connectable conductor cross section multi-wired
1
-
Pollution degree
3
-
Nominal voltage
230
-
Delay adjustable
FALSE
-
Surge current capacity
3
-
Ambient temperature during operating
-25
-
Rated fault current
0.3
-
Rated fault current adjustable
FALSE
-
Leakage current type
EV000896
-
Nominal current
125
-
Anti-nuisance tripping version
TRUE
-
Rated impulse withstand voltage Uimp
6
-
Connectable conductor cross section solid-core
1
-
Rated insulation voltage Ui
500
-
Frequency
EV008013
-
With interlocking device
FALSE
-
Max. delay time
This Acti9 C60PV-DC product is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles and 25A In rated current and B tripping curve. The rated short circuit breaking capacity goes up to 3kA at 650VDC conforming to standard and at conforming to standard. This product complies with EN/IEC 60947-2 standard. This miniature circuit breaker combines functions of circuit protection against short circuit and overload current, control and isolation. It is designed to protect cables located between each string of photovoltaic modules. It will be installed in a string protection enclosure at the end of each string of photovoltaic modules combined with a switch. It is dedicated to multi string photovoltaic installations. Mechanical durability goes up to 20000 cycles and electrical durability goes up to 1500 cycles. The Ue operational voltage is going from 800VDC. The Ui rated insulation voltage is 1000VDC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is . It can be mounted on DIN rail for modular installation. Its width is 8 pitches of 9mm. The product colour is white (RAL9003). The dimensions are (W) 72 mm x (H) 132.7 mm x (D) 77.4 mm. The weight is 0.545 kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -25°C to 70°C. The storage temperature is -40°C to 85°C.
