СКУ: MTN644492
Модул KNX 4 входа 10V
-
Brand
Schneider Electric
-
Nominal voltage
24
-
Degree of protection (IP)
EV006419
-
Bus system KNX radio
FALSE
-
Bus system Powernet
FALSE
-
Bus system KNX
FALSE
-
Bus system LON
FALSE
-
With bus connection
FALSE
-
Bus system radio frequent
FALSE
-
Other bus systems
EV000494
-
Radio frequent bidirectional
FALSE
-
Temperature control with built-in continuous control
FALSE
-
Voltage supply over bus
FALSE
-
Temperature and stroke indication
FALSE
-
Mounting method
EV003025
-
Buttons for manual operation at the drive
FALSE
KNX binary input REG-K/4x10. For connecting four conventional push-buttons or floating contacts to the KNX. Internally generates a signal voltage SELV, electrically isolated from the bus. With integrated bus coupler and plug-in screw terminals. The input voltage level is displayed at each input with a yellow LED. A green LED indicates that the device is ready for operation once the application has been loaded. For installation on DIN rails TH35 according to EN 60715. The bus is connected using a bus connecting terminal. a data rail is not necessary. KNX software functions:. Switching, dimming or blind control via 1 or 2 inputs. Positioning values for blind control (8-bit). Pulse edges with 1-, 2-, 4-, or 8-bit telegrams. Differentiation between short/long operation. Initialisation telegram. Cyclical sending. Pulse edges with 2-byte telegrams. 8-bit linear regulator. Disable function. Break/make contact. Debounce time. Inputs: 4. Contact voltage: max. 10 V, clocked. Contact current: max. 2 mA, pulsing. Cable length: max. 50 m. Device width: 2.5 modules, approx. 45 mm. Contents: With bus connecting terminal and cable cover. Colour: light grey.
