СКУ: TM5SE1IC01024
Модул. 1HSC INC 100KHZ 24VDC
-
Brand
Schneider Electric
-
SIL according to IEC 61508
EV000494
-
Performance level according to EN ISO 13849-1
EV000494
-
Explosion safety category for dust
EV000494
-
Explosion safety category for gas
EV000494
-
Appendant operation agent (Ex ia)
FALSE
-
Appendant operation agent (Ex ib)
FALSE
-
Suitable for safety functions
FALSE
-
Width
12.5
-
Height
99
-
Depth
75
-
Suitable for multi-axis positioning
FALSE
-
Suitable for weighing
FALSE
-
Suitable for temperature control
FALSE
-
Suitable for NC
FALSE
-
Suitable for SSI
FALSE
-
Suitable for welding control
FALSE
-
Suitable for pressure control
FALSE
-
Suitable for electronic positioning
FALSE
-
Suitable for CNC
FALSE
-
Suitable for detection absolute value
FALSE
-
Suitable for flux controller
FALSE
-
Suitable for flux measurement
FALSE
-
Suitable for flying saw
FALSE
-
Suitable for multi-axis control
FALSE
-
Suitable for path controller
FALSE
-
Suitable for cam controller
FALSE
-
Number of functions
2
-
Suitable for counting
TRUE
-
Suitable for single-axis positioning
TRUE
-
Suitable for single-axis controller
TRUE
-
Suitable for incremental data detection
TRUE
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This counter module provides 1 incremental encoder input. Its counting frequency is 100kHz per channel. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an insulation between channel and bus at 500Vrms AC and no insulation between channels. The maximum cycle time is 2ms and counter input resolution is 16bit/32bit. It is an IP20 rated product. The housing colour is white. It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 motion controller and Modicon M258 logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
