СКУ: GV4AU247

MN - минималнов напреженов изключвател - 220...240V AC 50Hz 208…240V AC 60Hz - for TeSys GV4

  • Brand
    Schneider Electric
  • Voltage type for actuating
    EV000460
  • Suitable for power circuit breaker
    TRUE
  • Rated control supply voltage Us at AC 50HZ
    220
  • Suitable for motor safety switch
    FALSE
  • Suitable for off-load switch
    FALSE
  • Suitable for overload relay
    FALSE
  • Type of electric connection
    EV005752
  • Delayed
    FALSE
  • Rated control supply voltage Us at AC 60HZ
    208
  • Number of contacts as normally open contact
  • Number of contacts as normally closed contact
  • Number of contacts as change-over contact

TeSys GV electrical trip unit, MN undervoltage release, 208-240V AC 50/60Hz, for motor circuit breakers GV4. Opening of the the circuit breaker is ensured when the control voltage drops below 0.35 Uc, and possible between 0.35-0.7 Uc. Closing of the circuit breaker is possible when the control voltage is in limits 0.85-1.1 Uc. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA).
