Миниатюрен клемен блок Linergy - 2.5mm? 24A 1x1 с винт - black | Spark & Co
  • 3D
|

СКУ: NSYTRV22MBL

Миниатюрен клемен блок Linergy - 2.5mm? 24A 1x1 с винт - black

  • Brand
    Schneider Electric
  • Rated voltage
    500
  • Number of levels
    1
  • Type of electrical connection 1
    EV000415
  • Internally connected stages
    FALSE
  • Inflammability class of insulation material according to with UL94
    EV004429
  • Material insulation body
    EV000403
  • Colour
    EV000080
  • Depth
    30
  • Height
    34
  • Type of electrical connection 2
    EV000415
  • Mounting method
    EV005504
  • Connectable conductor cross section solid-core
    0.2
  • Closing plate required
    TRUE
  • Connectable conductor cross section fine-strand with cable end sleeve
    0.2
  • Explosion-tested version 'Ex e'
    TRUE
  • Connectable conductor cross section multi-wired
    0.2
  • Operating temperature
    -40
  • Number of clamp positions per level
    2
  • Connectable conductor cross section fine-strand without cable end sleeve
    0.2
  • Width
    5.2
  • Rated current In
    24

Linergy TR is Mini terminal block for Linergy. It belongs to linergy Miniature passthrough terminal block with 2.5 mm² nominal cross section. The rated operational voltage is 600V conforming to CSA/UL and 500V conforming to EN/IEC 60947-7-1. The rated current is 24A conforming to EN/IEC 60947-7-1 and 20A conforming to CSA/UL. It has Blue surface treatment. Mounting by clip-on and sideways connection by single-level 1x1 screw terminals. It could be connection and disconnection by screwdriver. It is compatible with spacial enclosures for PrismaSeT G, PrismaSeT P, PrismaSeT HD, PrismaSeT Pack 250, PanelSeT, Mureva Enclosure, PrismaSeT XS, Tesys. Sold in lots of 50 units. Ambient air temperature for operation is from -40 to 130 °C conforming to IEC 60216-1 and VDE 0304-T21. Multi standards certified (UL, CSA, VDE).
