Миниатюрен автоматичен прекъсвач - 4P - 40A - крива K

This Acti9 iC60L product is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, the In rated current is 1A, and a C tripping curve. The Icn rated short circuit breaking capacity goes up to 100kA at 380VAC to 415VAC conforming to EN/IEC 60947-2 standard and 15000A at 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60947-2 and residential standard EN/IEC 60898-1. This miniature circuit breaker protects against short circuit and overload current in all applications. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC 60898-1 standard) improves downstream circuit protection cost. It is DIN rail mountable. The width in 9mm pitches is 4. The pollution degree is 3. The overvoltage category is IV. The product colour is white (RAL 9003). The dimensions are (W) 36mm x (H) 85mm x (D) 78.5mm. The weight is 0.25kg. According to IEC 60529 standard, the IP degree of protection is IP20 and becomes IP40 once in a modular enclosure. The operating temperature is from -35°C to 70°C. The storage temperature is from -40°C to 85°C.
