СКУ: M9F10350
Миниатюрен авт. прекъсвач C60N 3P 50A B 415V 10KA
-
Brand
Schneider Electric
-
Rated voltage
240
-
With auto test for earth leakage function
FALSE
-
Width in number of modular spacings
0.5
-
Suitable for max. number of poles main contact unit (total)
4
-
Number of contacts as change-over contact
1
-
Number of fault-signal switches
1
-
Voltage type for actuating
EV000509
-
Installed at the factory
FALSE
-
Number of contacts as normally closed contact
-
Number of contacts as normally open contact
-
Device fitting
EV009775
-
Additional equipment
EV009833
-
Suitable for max. current main contact unit
63
-
Rated switch current
0.1
This Multi9 C60N is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 32A rated current and B tripping curve. The rated short circuit breaking capacity goes up to 10kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with EN/IEC 60947-2 and GB/T 14048.2 industrial standards. It has been designed to offer enhanced protection by preventing, protecting equipment from electrical threats. This product protects from short circuit and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
