СКУ: NSYBN206
M6 пластм.плъзгаща гайка за C20
-
Brand
Schneider Electric
-
Material
EV000179
-
Thread type
EV003712
-
Surface protection
EV003454
-
With washer
FALSE
-
Thread size (metric)
6
-
With thread end
FALSE
-
Material click-mount element
EV000154
-
With clamping plate
FALSE
-
With hexagonal nut
FALSE
-
Clickable
FALSE
-
With spring
FALSE
DLM chassis for PanelSeT S3D, PanelSeT S3X and PanelSeT CRN enclosures The chassis is to be fixed on front of enclosure and step slide by fixing elements and back with supports location The width is 555mm The height is 753mm The depth is 101,5mm Number of 18mm modules is 84 (1 module = 2 steps = 18 mm) Number of horizontal rows is 3 The depth of the chassis can be adjusted in height from 40 to 85mm for DIN rail The product is made from grey steel (RAL 7035) The front has a grey (RAL 7035) color Number of cut-outs is 3 The kit is made up of 1 chassis structure, 2 finish covers, 1 neutral/earth strip 2 x 16 mm² 5 x 6 mm², 3 front panels with 35mm DIN rails and 1 plain front panel with mounting plate Anti-corrosion protection is ensured by an polyester powder coating
