СКУ: LP1K09008ED
Контактор 2P+2R VIS 48V DC
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Voltage type for actuating
EV000461
-
Modular version
FALSE
-
Rated operation current Ie at AC-1, 400 V
20
-
Number of normally closed contacts as main contact
2
-
Number of normally open contacts as main contact
2
-
Rated control supply voltage Us at DC
42
-
Number of auxiliary contacts as normally closed contact
-
Number of auxiliary contacts as normally open contact
TeSys K contactor, 4 poles (2NO+2NC), for non-inductive load control applications up to 20A/690V AC-1. It provides a 48V DC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).
