СКУ: 83109
Контакт за стенен монтаж 16A 3PNT
-
Brand
Schneider Electric
-
Material
EV000139
-
Cable entry
EV004016
-
Connection system
EV001008
-
Type of fastening
EV009034
-
Insulated mounting
FALSE
-
Voltage according to EN 60309-2
EV011415
-
Identification colour
EV000233
-
Degree of protection (IP)
EV006423
-
Clock hour position
6
-
Military model
FALSE
-
Number of poles
5
-
IEC-amperage
16
This Mureva PK socket with completely loosened captive screws connection is wall mounted. It has 2P+E poles, rated current is 16A and the operating voltage is 200VAC to 250VAC. The dimensions of the base plate are (W) 80mm x (H) 155mm. The degree of protection is IP67 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The size of the cable entries in 16A is 8mm to 15mm for 1mm² to 4mm² cables. The color of the socket is light grey (RAL 7035) with blue easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 6h.
