СКУ: PKF16W435
Контакт за стена 16A IP44 3Р+N+Е PKF16W435
-
Brand
Schneider Electric
-
Material
EV000139
-
RAL-number
7035
-
Number of poles
4
-
Rated frequency
50
-
Connection system
EV001008
-
Identification colour
EV000233
-
Degree of protection (IP)
EV006423
-
Clock hour position
6
-
Military model
FALSE
-
Cable entry
EV000494
-
Angle of plug
EV000409
-
Voltage according to EN 60309-2
EV009026
-
Rated voltage
380
-
IEC-amperage
16
-
Flange size horizontal
65
-
Drill hole distance horizontal
52
-
Flange size vertical
85
This Mureva PK socket with captive screws connection is angled panel mounted. It has 3P+E poles, rated current is 16A and the operating voltage is 400VAC. The dimensions of the base plate are (W) 81mm x (H) 85mm. The degree of protection is IP67 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The cross section of the cables in 16A is 1mm² to 4mm². The color of the socket is light grey (RAL 7035) with red easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 6h.
