СКУ: A9XPE210

Комплект от 10 капачета за Acti 9, 2 полюса

  • Brand
    Schneider Electric
  • Number of poles
    1
  • Colour
    EV000202
  • Insulated
    TRUE
  • Cross section
    16
  • Number of phases
    1
  • Type of electric connection
    EV000158
  • Suitable for devices with N-conductor
    FALSE
  • Rated permanent current Iu
    100
  • Suitable for devices with auxiliary switch
    TRUE
  • Module width
    18
  • Max. rated operation voltage Ue
    415
  • Length
    1000
  • Width in number of modular spacings
    57
  • Suitable for number of devices
    57

This Acti9 product is a cuttable horizontal comb busbar 57 modules for Acti9 C60. It is dedicated to 1L installations. The type is L1 (Line). It is a set of 1 device. It is suitable for 57 devices (1P). The length is 1000mm.The total number of modules of 18mm is 57. The number of phase is 1. The number of poles is 2. The Ie rated operational current at 40°C is 100A. The Isc short circuit current is compatible with the breaking capacity of Schneider Electric circuit breakers. The Ui rated insulation voltage is 500VAC. The Ue rated operational voltage is 415VAC. The color of the device is anthracite grey RAL7016. The pollution degree is 3. According to IEC 60695-2-1 standard the fire resistance is self-extinguishing at 960°C within 30s.
