СКУ: A9L65301
Кат. отводител PRD 65R 65KA 340V 3P with report A9L65301
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Concurrently switching neutral conductor
FALSE
-
Frequency
50
-
Additional equipment possible
TRUE
-
Flush-mounted installation
FALSE
-
Explosion-proof
FALSE
-
Connectable conductor cross section solid-core
1.5
-
Over voltage category
4
-
Connectable conductor cross section multi-wired
1
-
Pollution degree
3
-
Width in number of modular spacings
1.5
-
Number of poles (total)
1
-
Number of protected poles
1
-
Rated current
63
-
Release characteristic
EV000074
-
Rated voltage
415
-
Ambient temperature during operating
-25
-
Built-in depth
44
-
Rated impulse withstand voltage Uimp
6
-
Voltage type
EV000460
-
Rated insulation voltage Ui
500
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
3
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
10
-
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10
-
Current limiting class
1
This Acti9 iPRD40 surge arrester protects 1P installations. It allows quick replacement of damaged cartridges. This Type 2 device is recommended for high risk level and incoming panel board. It can be turned over to allow the phase/neutral/earth cables to enter through either the top or the bottom. The associated circuit breaker Isc breaking capacity can go up to 50kA. This Acti9 iPRD40 is compatible with TT and TN-S earthing system. The Uc maximum continuous operating voltage in common mode (L/PE or N/PE) is 350VAC. The Up Voltage protection level in common mode (between phase and earth) is 1.4kV. The Ue rated operational voltage is 230VAC +/- 10%. The product colour is white (RAL9003).The dimensions are (W) 18mm x (H) 85mm x (D) 69mm. The weight is 110g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards.
