СКУ: A9S61220
iSW 2P 20A
-
Brand
Schneider Electric
-
Number of contacts as normally open contact
1
-
Number of poles
1
-
Degree of protection (IP)
EV006405
-
Width in number of modular spacings
1
-
Rated current
32
-
Voltage type
EV000460
-
Imprint/indication
EV000154
-
Number of contacts as normally closed contact
-
Number of contacts as change-over contact
-
Lamp type
EV002125
-
Rated voltage
250
-
Forced segregation (according to DIN VDE 0113)
TRUE
-
With signal lamp
TRUE
-
Colour calotte
EV000233
-
Built-in depth
75.5
-
Switching function
EV007122
-
Min. rated voltage
230
-
Max. lamp power
1.2
This Acti9 iSW is a modular and reliable switch disconnector. it is a 3P, rated current is 20A, and operating voltage is 415VAC. Electrical endurance goes up to 30000 cycles, and Mechanical endurance goes up to 300000 cycles. The operating temperature is -20°C to +50°C. The storage temperature is -40°C to +70°C. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. The width in 9mm pitches is 4. The dimensions are (W) 36mm x (H) 77mm x (D) 70mm. This switch disconnector is used for control. This product is compliant with EN/IEC 60669-2-4.
