СКУ: 170ADI35000
Дискретен модул Modicon Momentum, 32 цифрови входа, 24V DC
-
Brand
Schneider Electric
-
SIL according to IEC 61508
EV000494
-
Performance level according to EN ISO 13849-1
EV000494
-
Explosion safety category for dust
EV000494
-
Explosion safety category for gas
EV000494
-
Voltage type of supply voltage
EV000461
-
Appendant operation agent (Ex ia)
FALSE
-
Appendant operation agent (Ex ib)
FALSE
-
Suitable for safety functions
FALSE
-
Supply voltage DC
24
-
Type of electric connection
EV000154
-
Digital inputs configurable
FALSE
-
Depth
40
-
Short-circuit protection, outputs available
FALSE
-
Type of digital output
EV000494
-
Digital outputs configurable
FALSE
-
Width
125
-
Type of voltage (input voltage)
EV000461
-
Number of digital inputs
32
-
Input current at signal 1
2.5
-
Permitted voltage at input
-3
-
Time delay at signal exchange
3.3
-
Height
141.5
-
Number of digital outputs
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base DC module offers 2 groups of 16 inputs, conforming to IEC 1131-2 type 1 with positive discrete input logic. It is a module with discrete input voltage of 24V DC. There is an isolation between channels and ground at 500V AC. It features 32 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.2kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
