СКУ: CCTFR6100
Connected Radiator Thermostat, Wiser, white
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006410
-
Bus system radio frequent
TRUE
-
Bus system KNX radio
FALSE
-
Bus system Powernet
FALSE
-
Bus system KNX
FALSE
-
Bus system LON
FALSE
-
Radio frequent bidirectional
TRUE
-
With bus connection
TRUE
-
Other bus systems
EV011012
-
Nominal voltage
3
-
Voltage supply over bus
FALSE
-
Temperature and stroke indication
FALSE
-
Mounting method
EV003025
-
Function master/slave
TRUE
-
Temperature control with built-in continuous control
TRUE
-
Buttons for manual operation at the drive
TRUE
The Schneider Electric Wiser radiator thermostat uses integrated temperature sensors to control the flow of water through a radiator, thereby regulating the temperature in a room. It allows to maintain the room temperature at the set value. The Wiser Radiator Thermostat maintains the simplistic style and builds on years of success as a leading TRV manufacturer with a host of additional features. With a connection to the boiler, via the Heat HubR, it allows you to control the On/Off times and temperatures of individual rooms using the intuitive app. It has 3 types of control, screw cap for temperature change +/- 2°C, with a remote control or via the SE mobile application. The colour of the the device is White (RAL 9016). This device uses for power supply 2 x 1.5V IEC LR6 - AA Alkaline batteries. The battery life is 2 years on average. The Wiser Hub is connected to the internet via a domestic internet box, it can also be controlled from Alexa and Google Home virtual assistants. Pair the Wiser Radiator Thermostat with a Wiser Hub which can manage up to 16 rooms with a maximum of 4 radiators per room. The dimensions are (H) 93mm and diameter 51mm including an adapter. The wireless room thermostat is battery powered and, thanks to the handy table stand and wall clip, can be positioned anywhere. It is easy to use via three touch buttons to access and change settings with indicators for setting the temperature, current room temperature and humidity. The operating temperature is from 0°C to 45°C. The Storage temperature is from -10°C to 55°C. The radio signal range is up to 30m in open field. This device uses a radio technology Zigbee 3.0. The Frequency is 2.4GHz (Bi-directional, Mesh). The maximum radio-frequency power is +13dBm (20mW). In a room with a single radiator the Wiser Radiator thermostat is controlled by Wiser Hub. In a room with several radiators the Wiser Radiator the room temperature is provided collectively by a Wiser Room thermostat in order to ensure a balanced comfort.
