СКУ: KBB40ZJ4W

CANALIS JUNCTION KBB бял

  • Brand
    Schneider Electric
  • Number of poles
    3
  • RAL-number
    7035
  • Colour
    EV000270
  • Degree of protection (IP)
    EV006420
  • Protection
    EV011677
  • Width
    53
  • Height
    68
  • Number of CEE socket outlets
  • With adjustment
    TRUE
  • Number of NEMA socket outlets
  • Phase selection
    TRUE
  • Branch off type
    EV000381
  • Rated voltage at AC 50 Hz
    230
  • Number of conductors (without earthing)
    2
  • Rated current at AC 50 Hz
    16
  • Length
    160
  • Number of other socket outlets
    1
  • Type of socket outlets
    EV010063

This is an additional jointing unit for Canalis KBB busbar trunking. Canalis KBB is designed for lighting and power socket distribution. The rated operational current is 40A at 35°C. The rated operational voltage is from 230VAC to 400VAC 50/60Hz. This element is clipped on the lines to make the electrical junction. It embeds 1 electrical circuit with 3L+N+PE polarity. It provides IP55 protection conforming to IEC 60529 standard, which guarantees trunking protection against splashes and dust. It provides IK06 protection conforming to IEC 62262 standard against external mechanical impacts. It is made off RAL 9003 white lacquered sheet steel. Canalis KBB is compliant with IEC/EN 61439-6 standard. It is non flame propagating as per the recommendations of IEC 60332-3 standard. All the insulating and plastic materials are halogen free and have enhanced fire withstand capabilities (IEC 60695-2).
