СКУ: C25N3MA150

Автоматичен прекъсвач NSX250N 50kA AC 3P3D 150A MA

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Number of poles
    3
  • Device construction
    EV009211
  • Rated operating voltage
    690
  • Degree of protection (IP)
    EV006415
  • With integrated under voltage release
    FALSE
  • Width
    105
  • Type of control element
    EV000154
  • With integrated auxiliary switch
    FALSE
  • Switch off technique
    EV006116
  • With thermal protection
    FALSE
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    50
  • Height
    161
  • Phase failure sensitive
    FALSE
  • Rated permanent current Iu
    150
  • Depth
    86
  • Adjustment range undelayed short-circuit release
    1350

This ComPacT NSX250N is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 150A rating magnetic trip unit (MA). MA trip unit provides an adjustable magnetic protection for instantaneous tripping. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX250N is part of Schneider Electric EcoStruxure Power architecture.
