Автоматичен прекъсвач, ComPacT NSX250R, 200kA/415VAC, 3 полюса, MicroLogic 6.2E-M изключвателно устройство 220A | Spark & Co
  • 3D
|

СКУ: C25R36M220

Автоматичен прекъсвач, ComPacT NSX250R, 200kA/415VAC, 3 полюса, MicroLogic 6.2E-M изключвателно устройство 220A

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Number of poles
    3
  • Device construction
    EV009211
  • Rated operating voltage
    690
  • Degree of protection (IP)
    EV006415
  • With integrated under voltage release
    FALSE
  • Width
    105
  • Type of control element
    EV000154
  • With integrated auxiliary switch
    FALSE
  • Phase failure sensitive
    TRUE
  • With thermal protection
    TRUE
  • Overload release current setting
    70
  • Height
    161
  • Switch off technique
    EV000101
  • Rated permanent current Iu
    150
  • Depth
    86
  • Adjustment range undelayed short-circuit release
    2250
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    200

This ComPacT NSX250R is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 200kA rms at 415VAC 50/60Hz and 45kA rms at 690VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic MicroLogic 5.2 E trip unit, with 100A rating. MicroLogic 5.2 E trip unit provides adjustable long time, short time and instantaneous protection. MicroLogic 5.2 E has an embedded display unit for fine settings adjustment and display of the energy (energy meter). This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX250R is part of Schneider Electric EcoStruxure Power architecture.
