СКУ: EZ9F35225
Автом. прекъсвач Easy9 MCB XP 2P 6000 C Curve 25A
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Concurrently switching neutral conductor
FALSE
-
Width in number of modular spacings
1
-
Frequency
50
-
Release characteristic
EV000084
-
Flush-mounted installation
FALSE
-
Explosion-proof
FALSE
-
Connectable conductor cross section multi-wired
1
-
Number of poles (total)
1
-
Number of protected poles
1
-
Rated current
20
-
Rated voltage
230
-
Ambient temperature during operating
-25
-
Voltage type
EV000460
-
Connectable conductor cross section solid-core
1
-
Over voltage category
3
-
Pollution degree
2
-
Rated impulse withstand voltage Uimp
4
-
Built-in depth
45
-
Additional equipment possible
FALSE
-
Current limiting class
3
-
Rated insulation voltage Ui
440
-
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
6
This Easy9 product is a modular bell. According to IEC 60529 standard, the IP degree of protection is IP20 and becomes IP40 once in a modular enclosure. The tunnel type terminal connection allows rigid and flexible copper cables with a cable cross section from 1mm² to 2.5mm². Ui rated insulation voltage is 250V. The Overvoltage category is 2. The Us rated supply voltage is 230VAC with an operating frequency of 50Hz. It can be mounted on the DIN rail for modular installation. The width in 9mm pitches is 2. The dimensions are (W) 18mm x (H) 81mm x (D) 66mm. The product colour is grey. The product weight is 77g. The pollution degree is 2. The relative humidity is 95% at 55°C. The wire stripping length is 12mm. The tightening torque of the connection is 1N.m. The IK degree of protection is IK04. The operating temperature is from -10°C to +40°C. The storage temperature is from -25°C to +60°C. This product complies with EN/IEC 62080 standard. It has CE and CMIM quality labels.
