СКУ: LV510425
Автом. прекъсвач CVS100NA 100A 3P SWITCH-DISCONNECTOR
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Version as emergency stop installation
FALSE
-
Version as reversing switch
FALSE
-
Suitable for front mounting centre
TRUE
-
Number of poles
3
-
Voltage release optional
FALSE
-
Device construction
EV009211
-
Version as maintenance-/service switch
FALSE
-
Version as safety switch
FALSE
-
Suitable for front mounting 4-hole
TRUE
-
Number of switches
1
-
Motor drive integrated
FALSE
-
Suitable for floor mounting
FALSE
-
Motor drive optional
FALSE
-
Version as main switch
TRUE
-
Interlockable
TRUE
-
Colour control element
EV000206
-
Suitable for distribution board installation
TRUE
-
Degree of protection (IP), front side
EV006415
-
Rated permanent current Iu
100
-
Rated permanent current at AC-23, 400 V
100
-
Number of auxiliary contacts as change-over contact
4
-
Type of control element
EV000421
-
Rated operating voltage
220
-
Suitable for intermediate mounting
TRUE
-
Rated short-time withstand current lcw
1.8
-
Max. rated operation voltage Ue AC
440
-
Number of auxiliary contacts as normally closed contact
-
Number of auxiliary contacts as normally open contact
This device is a 100A switch disconnector from EasyPact CVS100. This operational current(Ie) is both 100A, when is used for utilisation category AC22 or AC23. The rated short-time withstand current(Icw) is 1800A(1s). The version of device is 3 poles frame without tripping protection. It is conformed to standard EN/IEC60947-3 for switch disconnector products. This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95. It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation. The front of toggle offers IP40 protection, but when it is equiped extended rotary handle, additional IP54 protection degree for extended rotary handle. This series have slots for control auxiliaries(MN/MX),which is indicated contact status. The fixed dimension is 140mm(width).255mm(height),110mm(Depth),
