Автом. прекъсвач ComPacT NSX160F, 36kA/415VAC, 4P 3D (neutral not protected), TMD trip unit 125A

• Brand
  Schneider Electric
• Type of electrical connection of main circuit
  EV000415
• Device construction
  EV009211
• Motor drive integrated
  FALSE
• Rated permanent current Iu
  80
• Degree of protection (IP)
  EV006415
• Number of poles
  4
• Type of control element
  EV000421
• Rated voltage
  690
• Position of connection for main current circuit
  EV007926
• Integrated earth fault protection
  FALSE
• Motor drive optional
  TRUE
• Suitable for DIN rail (top hat rail) mounting
  FALSE
• With switched-off indicator
  TRUE
• With integrated under voltage release
  FALSE
• DIN rail (top hat rail) mounting optional
  TRUE
• Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
  36
• Number of auxiliary contacts as normally closed contact
• Number of auxiliary contacts as change-over contact
• Number of auxiliary contacts as normally open contact
• Complete device with protection unit
  TRUE
• Adjustment range undelayed short-circuit release
  640
• Overload release current setting
  56
