AO4 UI SL Mod

Discover the Schneider Electric New Unica roller blind push-button mechanism with central plate. The device has 1 module. The rocker method is used for operating. The device uses screw terminals. It has a clip-in fixing mode. The device has 1 module. The dielectric strength of this roller blind push-button is 2000 V. The Ue-rated operating voltage is 250VAC. The rated current is 10A with a frequency of 50Hz. The color of the device is white, and it has a glossy surface finish. The product complies with the EN 60669-1, LV directive standard. It has ISI, and CE product certifications. This device enables flush mounting, features a clip-in fixing mode, and utilizes screw terminals for secure connections. The dimensions of the product are (W) 22.5mm x (H) 45mm x (D) 40.6mm. Its embedding depth is 31.5mm. It has an IP4X and IK04 degrees of protection. The operating temperature is from -5°C up to +40°C and the storage temperature is from -5°C up to +50°C. New Unica is designed with clever features to be flexible, easy to understand, and quick to install, providing solutions for all customer requirements. New Unica is a modular range that offers a wide variety of products and functions with a sleek and timeless aesthetic that integrate well with other installations. It is designed with clever features to be flexible, easy to understand and quick to install, providing convenient solutions for customer requirements.
