СКУ: CCT15858

Acti 9 IHP DCF (24h/7d) програмируем смарт превключвател

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Mounting method
    EV000242
  • Width in number of modular spacings
    3
  • Height
    90
  • Width
    54
  • Voltage type of supply voltage
    EV000460
  • Supply voltage
    230
  • Suitable for manual operation
    TRUE
  • Automatic switching summer-/winter time
    FALSE
  • Potential free switch contact
    TRUE
  • Switching preselection
    TRUE
  • Nominal switching current at 250 V AC
    16
  • Quartz controlled
    FALSE
  • Mains synchronous
    FALSE
  • Number of channels
    1
  • Shortest switching time channel 1
    15
  • Frequency supply voltage
    50
  • 24 h program
    TRUE
  • Depth
    66
  • 60 min program
    FALSE
  • Weekly program
    FALSE
  • Annual program
    FALSE
  • Program shift divide 1
    15
  • Autonomy in hours
  • Max. switching power LED
    180

TH4 Thermostat. For individual and multifamily housing, tertiary premises, TH4 thermostat monitors and regulates ambient temperature from +8°C to +26°C according to 3 temperature set points. Comfort: while the promises are occupied. Reduced: while the premises are unoccupied. Above freezing: for a prolonged period of non-occupancy. Delivered with CCT15846 ambient temperature probe. Supply voltage: AC 230 V ± 10 %. Frequency: 50/60 Hz. Output change over switch: 16 A/250 V cos Phi 1. 3 A/250 V cos Phi 0.6. Consumption: < 4 VA. Temperature difference (difference in temperature between switch-on and switch-off): ± 0.2 degrees. Operating temperature: -10°C to +55°C. Storage temperature: -20°C to +60°C. Degree of protection: IP20B as per EN 60529. Connection terminals: 2 x 0.5 to 2.5 mm2, rigid and flexible wires. Overall dimensions: 5 modules. This product is the repacked version of commercial reference: CCT15841. The manufacturing date is authoritative in the application of the regulations. Refer to the original reference to consult the product documents.
