СКУ: A9XPH212

A9XPH212 Гребен 2P 100A 12mod

  • Brand
    Schneider Electric
  • Number of poles
    2
  • Colour
    EV000202
  • Insulated
    TRUE
  • Cross section
    16
  • Number of phases
    1
  • Type of electric connection
    EV000158
  • Width in number of modular spacings
    24
  • Suitable for devices with N-conductor
    TRUE
  • Rated permanent current Iu
    100
  • Length
    430
  • Suitable for devices with auxiliary switch
    TRUE
  • Module width
    18
  • Max. rated operation voltage Ue
    415
  • Suitable for number of devices
    12

This Acti9 product is a cuttable horizontal comb busbar 24 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to N+1L installations. The type is NL (Neutral, Line). It is a set of 1 device. It is suitable for 12 devices (1P+N). The length is 430mm. The total number of modules of 18mm is 24. The number of phase is 1. The number of poles is 2. The Ie rated operational current at 40°C is 100A. The Isc short circuit current is compatible with the breaking capacity of Schneider Electric circuit breakers. The Ui rated insulation voltage is 500VAC. The Ue rated operational voltage is 415VAC. The color of the device is white RAL9003. The pollution degree is 3. According to IEC 60695-2-1 standard the fire resistance is self-extinguishing at 960°C within 30s.
